Philips LPC2101 - Page 45

© Koninklijke Philips Electronics N.V. 2006. All rights reserved.
User manual Rev. 01 — 12 January 2006 45
Philips Semiconductors
UM10161
Volume 1 Chapter 5: VIC
Table 35: VIC register map
Name Description Access Reset
value
[1]
Address
VICIRQStatus IRQ Status Register. This register reads out the state of
those interrupt requests that are enabled and classified as
IRQ.
RO 0 0xFFFF F000
VICFIQStatus FIQ Status Requests. This register reads out the state of
those interrupt requests that are enabled and classified as
FIQ.
RO 0 0xFFFF F004
VICRawIntr Raw Interrupt Status Register. This register reads out the
state of the 32 interrupt requests / software interrupts,
regardless of enabling or classification.
RO 0 0xFFFF F008
VICIntSelect Interrupt Select Register. This register classifies each of the
32 interrupt requests as contributing to FIQ or IRQ.
R/W 0 0xFFFF F00C
VICIntEnable Interrupt Enable Register. This register controls which of the
32 interrupt requests and software interrupts are enabled to
contribute to FIQ or IRQ.
R/W 0 0xFFFF F010
VICIntEnClr Interrupt Enable Clear Register. This register allows
software to clear one or more bits in the Interrupt Enable
register.
WO 0 0xFFFF F014
VICSoftInt Software Interrupt Register. The contents of this register are
ORed with the 32 interrupt requests from various peripheral
functions.
R/W 0 0xFFFF F018
VICSoftIntClear Software Interrupt Clear Register. This register allows
software to clear one or more bits in the Software Interrupt
register.
WO 0 0xFFFF F01C
VICProtection Protection enable register. This register allows limiting
access to the VIC registers by software running in privileged
mode.
R/W 0 0xFFFF F020
VICVectAddr Vector Address Register. When an IRQ interrupt occurs, the
IRQ service routine can read this register and jump to the
value read.
R/W 0 0xFFFF F030
VICDefVectAddr Default Vector Address Register. This register holds the
address of the Interrupt Service routine (ISR) for
non-vectored IRQs.
R/W 0 0xFFFF F034
VICVectAddr0 Vector address 0 register. Vector Address Registers 0-15
hold the addresses of the Interrupt Service routines (ISRs)
for the 16 vectored IRQ slots.
R/W 0 0xFFFF F100
VICVectAddr1 Vector address 1 register. R/W 0 0xFFFF F104
VICVectAddr2 Vector address 2 register. R/W 0 0xFFFF F108
VICVectAddr3 Vector address 3 register. R/W 0 0xFFFF F10C
VICVectAddr4 Vector address 4 register. R/W 0 0xFFFF F110
VICVectAddr5 Vector address 5 register. R/W 0 0xFFFF F114
VICVectAddr6 Vector address 6 register. R/W 0 0xFFFF F118
VICVectAddr7 Vector address 7 register. R/W 0 0xFFFF F11C
VICVectAddr8 Vector address 8 register. R/W 0 0xFFFF F120
VICVectAddr9 Vector address 9 register. R/W 0 0xFFFF F124
VICVectAddr10 Vector address 10 register. R/W 0 0xFFFF F128
VICVectAddr11 Vector address 11 register. R/W 0 0xFFFF F12C
