Volume 1 Chapter 6: Pin configuration
P0.2/SCL0/
CAP0.0
18
[3]
22
[3]
I/O P0.2 — General purpose Input/output digital pin (GPIO).
I/O SCL0 — I
2
C0 clock Input/output. Open-drain output (for
I
2
C-bus compliance).
I CAP0.0 — Capture input for Timer 0, channel 0.
P0.3/SDA0/
MAT0.0
21
[3]
25
[3]
I/O P0.3 — General purpose Input/output digital pin (GPIO).
I/O SDA0 — I
2
C0 data input/output. Open-drain output (for
I
2
C-bus compliance).
O MAT0.0 — PWM output for Timer 0, channel 0.
P0.4/SCK0/
CAP0.1
22
[4]
26
[4]
I/O P0.4 — General purpose Input/output digital pin (GPIO).
I/O SCK0 — Serial clock for SPI0. SPI clock output from master
or input to slave.
I CAP0.1 — Capture input for Timer 0, channel 1.
P0.5/MISO0/
MAT0.1
23
[4]
27
[4]
I/O P0.5 — General purpose Input/output digital pin (GPIO).
I/O MISO0 — Master In Slave OUT for SPI0. Data input to SPI
master or data output from SPI slave.
O MAT0.1 — PWM output for Timer 0, channel 1.
P0.6/MOSI0/
CAP0.2
24
[4]
28
[4]
I/O P0.6 — General purpose Input/output digital pin (GPIO).
I/O MOSI0 — Master Out Slave In for SPI0. Data output from SPI
master or data input to SPI slave.
I CAP0.2 — Capture input for Timer 0, channel 2.
P0.7/SSEL0/
MAT2.0
28
[2]
31
[2]
I/O P0.7 — General purpose Input/output digital pin (GPIO).
I SSEL0 — Slave Select for SPI0. Selects the SPI interface as
a slave.
O MAT2.0 — PWM output for Timer 2, channel 0.
P0.8/TXD1/
MAT2.1
29
[4]
32
[4]
I/O P0.8 — General purpose Input/output digital pin (GPIO).
O TXD1 — Transmitter output for UART1.
O MAT2.1 — PWM output for Timer 2, channel 1.
P0.9/RXD1/
MAT2.2
30
[2]
33
[2]
I/O P0.9 — General purpose Input/output digital pin (GPIO).
I RXD1 — Receiver input for UART1.
O MAT2.2 — PWM output for Timer 2, channel 2.
P0.10/RTS1/
CAP1.0/AD0.3
35
[4]
38
[4]
I/O P0.10 — General purpose Input/output digital pin (GPIO).
O RTS1 — Request to Send output for UART1.
I CAP1.0 — Capture input for Timer 1, channel 0.
I AD0.3 — Analog Input 3.
P0.11/CTS1/
CAP1.1/AD0.4
36
[3]
39
[3]
I/O P0.11 — General purpose Input/output digital pin (GPIO).
I CTS1 — Clear to Send input for UART1.
I CAP1.1 — Capture input for Timer 1, channel 1.
I AD0.4 — Analog Input 4.
P0.12/DSR1/
MAT1.0/AD0.5
37
[4]
40
[4]
I/O P0.12 — General purpose Input/output digital pin (GPIO).
I DSR1 — Data Set Ready input for UART1.
O MAT1.0 — PWM output for Timer 1, channel 0.
I AD0.5 — Analog Input 5.
Table 58: Pin description
…continued
Symbol LQFP48 PLCC44 Type Description
