User’s Manual of IGS-4215-16T2S
122
• PartnerSysId
The system ID of link partner. This field would be updated when the port receives
LACP PDU from link partner.
• PnKey
Port key of partner. This field would be updated when the port receives LACP
PDU from link partner.
• AtKey
Port key of actor. The key is designed to be the same as trunk ID.
• Sel
LACP selection logic status of the port
 “S” means selected.
 “U” means unselected.
 “D” means standby.
• Mux
LACP mux state machine status of the port.
 “DETACH” means the port is in detached state.
 “WAIT” means waiting state.
 “ATTACH” means attach state.
 “CLLCT” means collecting state.
 “DSTRBT” means distributing state.
• Receiv
LACP receive state machine status of the port.
 “INIT” means the port is in initialize state.
 “PORTds” means port disabled state.
 “EXPR” means expired state.
 “LACPds” means LACP disabled state.
 “DFLT” means defaulted state.
 “CRRNT” means current state.
• PrdTx
LACP periodic transmission state machine status of the port.
 “no PRD” means the port is in no periodic state.
 “FstPRD” means fast periodic state.
 “SlwPRD” means slow periodic state.
 “PrdTX” means periodic TX state.
• AtState
The actor state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
“Expired”.
The contents could be true or false. If the contents are false, the web shows “_”; if
the contents are true, the web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and “E” for
each content respectively.
• PnState
The partner state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
“Expired”.
The contents could be true or false. If the contents are false, the web will show
“_”; if the contents are true, the Web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and “E”
for each content respectively.
