4.6.8 STP Statistics
This page displays STP statistics. The STP statistics screen in Figure 4-6-17 appears.
Figure 4-6-17: STP Statistics Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• Configuration BPDUs Received
Displays the current configuration BPDUs received.
• TCN BPDUs Received
Displays the current TCN BPDUs received.
• MSTP BPDUs Received
Displays the current MSTP BPDUs received.
• Configuration BPDUs
Transmitted
Displays the configuration BPDUs transmitted.
• TCN BPDUs Transmitted
Displays the current TCN BPDUs transmitted.
• MSTP BPDUs Transmitted
Displays the current BPDUs transmitted.
