User’s Manual of IGS-4215-16T2S
Figure 4-8-17: Forbidden Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port Mask
Displays the current port mask.
4.8.7 IGMP Forward All
This page provides IGMP Forward All. The Forward All screen in Figure 4-8-18 appears.
Figure 4-8-18: Forward All Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list to assign IGMP membership.
• Port
The switch port number of the logical port.
• Membership
Select IGMP membership for each interface:
Forbidden: Interface is forbidden from automatically joining the IGMP via MVR.
