User’s Manual of IGS-4215-16T2S
4.2.3 IPv6 Configuration
The IPv6 Configuration includes Auto Configuration, IPv6 Address and Gateway. The configured column is used to view or
change the IPv6 configuration. Fill out the Auto Configuration, IPv6 Address and Gateway for the device. The screens in Figure
4-2-4 and Figure 4-2-5 appear.
Figure 4-2-4: IPv6 Address Setting Page Screenshot
The page includes the following fields:
Object Description
• Auto Configuration
Enable IPv6 auto-configuration by checking this box.
If it fails, the configured IPv6 address is zero. The router may delay responding to
a router solicitation for a few seconds; the total time needed to complete
auto-configuration can be significantly longer.
• IPv6 Address
Provide the IPv6 address of this switch.
IPv6 address is in 128-bit records represented as eight fields of up to four
hexadecimal digits with a colon separating each field (:). For example,
'fe80::215:c5ff:fe03:4dc7'.
The symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can only appear
once. It also uses the following legally IPv4 address.
For example, ':192.1.2.34'.
Provide the IPv6 Prefix of this switch.
The allowed range is 1 through 128.
• Gateway
Provide the IPv6 gateway address of this switch.
IPv6 address is in 128-bit records represented as eight fields of up to four
hexadecimal digits with a colon separating each field (:).
For example, 'fe80::215:c5ff:fe03:4dc7'.
• DHCPv6 Client
To enable this Industrial Managed Switch to accept a configuration from a
Dynamic Host Configuration Protocol version 6 (DHCPv6) server.
By default, the Industrial Managed Switch does not perform DHCPv6 client
To Next Page
