User’s Manual of IGS-4215-16T2S
4.13.2 Access Method Profile Rules
4.13.2.1 Profile Rules
The Profile Rule Table Setting and Table screens in Figure 4-13-9 and Figure 4-13-10 appear.
Figure 4-13-9: Profile Rule Table Setting Page Screenshot
The page includes the following fields:
Object Description
• Access Profile Name
(1-32 characters)
Indicates the access profile name.
• Priority (1-65535)
Set priority.
The allowed value is from 1 to 65535.
• Management Method
Indicates the host can access the switch from
HTTP/HTTPs/telnet/SSH/SNMP/All interface that the host IP address matched
the entry.
• Action
An IP address can contain any combination of permit or deny rules.
(Default: Permit rules)Sets the access mode of the profile; either permit or
deny.
• Port
Select port for this drop down list.
• IP-Source
Indicates the IP address for the access management entry.
Buttons
: Click to apply changes.
Figure 4-13-10: Profile Rule Table Page Screenshot
