Planet IGS-4215 Series User Manual

User’s Manual of IGS-4215-16T2S
19
1.5 Product Specifications
Product IGS-4215-16T2S
Hardware Specifications
Copper Ports 16 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
Gigabit SFP Slots 2 100/1000BASE-SX/LX/BX SFP interfaces
Console 1 RJ45 serial port (115200,8, N, 1)
Switch Architecture
Store-and-Forward
Switch Fabric
36Gbps (non-blocking)
Switch Throughput@64 bytes
26.79Mpps@ 64 bytes
MAC Address Table 8K entries
Shared Data Buffer
4.1Mbits
Flow Control
IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame 10 Kbytes
ESD Protection
6KV DC
Enclosure
IP30 aluminum case
Installation
DIN-rail kit and wall-mount ear
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
LED
System
 Green: DC Power 1
 Green: DC Power 2
 Red: Power Fault
Per 10/100/1000T RJ45 Ports
 Green: 1000 LNK/ACT
 Orange: 10/100 LNK/ACT
Per SFP Interface
- Green: 1000 LNK/ACT
 Orange: 100 LNK/ACT
Connector
Removable 6-pin terminal block for power input
- Pin 1/2 for Power 1
- Pin 3/4 for fault alarm
- Pin 5/6 for Power 2
Alarm
One relay output for power failure.
Alarm relay current carry ability: 1A @ 24V DC
