User’s Manual of IGS-4215-16T2S
237
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Ingress Rate Limit (Kbps)
Displays the current ingress rate limit.
4.12.4.2 Egress Bandwidth Control
This page provides to select the egress bandwidth preamble. The Egress Bandwidth Control Setting and Status screens in
Figure 4-12-19 and Figure 4-12-20 appear.
Figure 4-12-19: Egress Bandwidth Control Settings Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port number from this drop-down list.
• State
Enable or disable the port rate policer. The default value is "Disabled".
• Rate (Kbps)
Configures the rate for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000.
Buttons
: Click to apply changes.
Figure 4-12-20: Egress Bandwidth Control Status Page Screenshot
