User’s Manual of IGS-4215-16T2S
82
• Undersize Packets
The total number of packets received that were less than 64 octets
• Oversize Packets
The total number of packets received that were longer than 1518 octets
• Fragments
The number of frames which size is less than 64 octets received with invalid CRC
• Jabbers
The number of frames which size is larger than 64 octets received with invalid
CRC
• Collisions
The best estimate of the total number of collisions on this Ethernet segment.
• 64 Bytes Frame
The total number of packets (including bad packets) received that were 64 octets
in length
• 65~127 Byte Frames
The total number of packets (including bad packets) received that were between
65 to 127 octets in length
• 128~255 Byte Frames
The total number of packets (including bad packets) received that were between
128 to 255 octets in length
• 256~511 Byte Frames
The total number of packets (including bad packets) received that were between
256 to 511 octets in length
• 512~1023 Byte Frames
The total number of packets (including bad packets) received that were between
512 to 1023 octets in length
• 1024~1518 Byte
Frames
The total number of packets (including bad packets) received that were between
1024 to 1518 octets in length
Buttons
: Click to clear the RMON statistics
4.2.8.2 RMON Event
Configure RMON Event table on this page. The RMON Event screens in Figure 4-2-40 & Figure 4-2-41 appear.
Figure 4-2-40: RMON Event Configuration Page Screenshot
