User’s Manual of IGS-4215-16T2S
Main Menu
Using the onboard Web agent, you can define system parameters, manage and control the Industrial Managed Switch, and all
its ports, or monitor network conditions. Via the Web-Management, the administrator can set up the Industrial Managed Switch
by selecting the functions those listed in the Main Function. The screen in Figure 4-1-5 appears.
Figure 4-1-5: Industrial Managed Switch Main Functions Menu
4.1.1 Save Button
This save button allows you to save the running/startup/backup configuration or reset switch in default parameter. The screen in
Figure 4-1-6 appears
Figure 4-1-6: Save Button Screenshot
The page includes the following fields:
Object Description
• Save Configuration
Click to save the configuration. For more detailed information, please refer to
chapter 4.1.2
