User’s Manual of IGS-4215-16T2S
208
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Selected VLAN
Displays the currently selected VLAN.
4.10.4 LLDP Local Device
Use the LLDP Local Device Information screen to display information about the switch, such as its MAC address, chassis ID,
management IP address, and port information. The Local Device Summary and Port Status screens in Figure 4-10-7 and
Figure 4-10-8 appear.
Figure 4-10-7: Local Device Summary Page Screenshot
The page includes the following fields:
Object Description
• Chassis ID Subtype
Displays the current chassis ID subtype.
• Chassis ID
Displays the current chassis ID.
• System Name
Displays the current system name.
• System Description
Displays the current system description.
• Capabilities Supported
Displays the current capabilities supported.
• Capabilities Enabled
Displays the current capabilities enabled.
• Port ID Subtype
Displays the current port ID subtype.
