User’s Manual of IGS-4215-16T2S
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• State
Displays the current LLDP status.
• Selected Optional
TLVs
Displays the current selected optional TLVs.
The VLAN Name TLV VLAN Selection and LLDP Port VLAN TLV Status screens in Figure 4-10-5 and Figure 4-10-6 appear.
Figure 4-10-5: VLAN Name TLV Selection Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port from this drop-down list.
• VLAN Select
Select VLAN from this drop-down list.
Buttons
: Click to apply changes.
Figure 4-10-6: LLDP Port VLAN TLV Status Page Screenshot
