User’s Manual of IGS-4215-16T2S
The page includes the following fields:
Object Description
• LLDP Enable
Displays the current LLDP status.
• LLDP PDU Disable
Action
Displays the current LLDP PDU disable action.
• Transmission Interval
Displays the current transmission interval.
• Holdtime Multiplier
Displays the current holdtime multiplier.
• Reinitialization Delay
Displays the current reinitialization delay.
• Transmit Delay
Displays the current transmit delay.
• LLDP-MED Fast Start
Repeat Count
Displays the current LLDP-MED Fast Start Repeat Count.
4.10.3 LLDP Port Setting
Use the LLDP Port Setting to specify the message attributes for individual interfaces, including whether messages are
transmitted, received, or both transmitted and received. The LLDP Port Configuration and Status screens in Figure 4-10-3 and
Figure 4-10-4 appear.
Figure 4-10-3: LLDP Port Configuration and Optional TLVs Selection Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port from this drop-down list.
• State
Enables LLDP messages transmit and receive modes for LLDP Protocol Data
Units. Options:
■ Tx only
■ Rx only
■ TxRx
■
