Planet IGS-4215 Series - Bandwidth Control; Ingress Bandwidth Control

User’s Manual of IGS-4215-16T2S
236
4.12.4 Bandwidth Control
Configure the switch port rate limit for the switch port on this page.
4.12.4.1 Ingress Bandwidth Control
This page provides to select the ingress bandwidth preamble. The Ingress Bandwidth Control Setting and Status screens in
Figure 4-12-17 and Figure 4-12-18 appear.
Figure 4-12-17: Ingress Bandwidth Control Settings Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port number from this drop-down list.
• State
Enable or disable the port rate policer. The default value is "Disabled".
• Rate (Kbps)
Configures the rate for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000.
Buttons
: Click to apply changes.
Figure 4-12-18: Ingress Bandwidth Control Status Page Screenshot
