User’s Manual of IGS-4215-16T2S
4.9.3 MLD Group Table
This page provides MLD Group Table. The MLD Group Table screen in Figure 4-9-6 appears.
Figure 4-9-6: MLD Group Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VID.
• Group IP Address
Displays multicast IP address for a specific multicast service.
• Member Port
Displays the current member port.
• Type
Member types displayed include Static or Dynamic, depending on selected
options.
• Life(Sec)
Displays the current life.
4.9.4 MLD Router Setting
Depending on your network connections, MLD snooping may not always be able to locate the MLD querier. Therefore, if the
MLD querier is a known multicast router/ switch connected over the network to an interface (port or trunk) on your Industrial
Managed Switch, you can manually configure the interface (and a specified VLAN) to join all the current multicast groups
supported by the attached router. This can ensure that multicast traffic is passed to all the appropriate interfaces within the
Industrial Managed Switch.
The MLD Router Setting screens in Figure 4-9-7 and Figure 4-9-8appear.
Figure 4-9-7: Add Router Port Page Screenshot
