Users Manual of IGS-4215-16T2S
210
4.10.5 LLDP Remote Device
This Page provides a status overview for all LLDP remote devices. The displayed table contains a row for each port on which an
LLDP neighbor is detected. The LLDP Remote Device screen in Figure 4-10-9 appears.
Figure 4-10-9: LLDP Remote Device Page Screenshot
The page includes the following fields:
Object Description
Local Port
Displays the current local port.
Chassis ID Subtype
Displays the current chassis ID subtype.
Chassis ID
The Chassis ID is the identification of the neighbor's LLDP frames.
Port ID Subtype
Displays the current port ID subtype.
Port ID
The Remote Port ID is the identification of the neighbor port.
System Name
System Name is the name advertised by the neighbor unit.
Time to Live
Displays the current time to live.
Buttons
: Click to delete LLDP removes device entry.
: Click to refresh LLDP remove device.
