User’s Manual of IGS-4215-16T2S
4.2.8 RMON
4.2.8.1 RMON Statistics
This page provides a Detail of a specific RMON statistics entry; RMON Statistics screen in Figure 4-2-39 appears.
Figure 4-2-39: RMON Statistics Detail Page Screenshot
The Page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• Drop Events
The total number of events in which packets were dropped by the probe due to
lack of resources
• Octets
The total number of octets of data (including those in bad packets) received on
the network
• Packets
The total number of packets (including bad packets, broadcast packets, and
multicast packets) received
• Broadcast Packets
The total number of good packets received that were directed to the broadcast
address
• Multicast Packets
The total number of good packets received that were directed to a multicast
address
• CRC/Alignment Errors
The total number of packets received that had a length (excluding framing bits,
but including FCS octets) of between 64 and 1518 octets
