User’s Manual of IGS-4215-16T2S
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port Mask
Displays the current port mask.
4.9.6 MLD Forward All
This page provides MLD Forward All. The Forward All screen in Figure 4-9-12 appears.
Figure 4-9-12: Forward All Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list to assign MLD membership.
• Port
The switch port number of the logical port.
• Membership
Select MLD membership for each interface:
Forbidden: Interface is forbidden from automatically joining the MLD via MVR.
None: Interface is not a member of the VLAN. Packets associated with
this VLAN will not be transmitted by the interface.
Static: Interface is a member of the MLD.
Buttons
: Click to apply changes.
