User’s Manual of IGS-4215-16T2S
101
4.3.5 Jumbo Frame
This page provides to select the maximum frame size allowed for the switch port. The Jumbo Frame screen in Figure 4-3-11
and Figure 4-3-12 appear.
Figure 4-3-11: Jumbo Frame Setting Page Screenshot
The page includes the following fields:
Object Description
• Jumbo Frame (Bytes)
Enter the maximum frame size allowed for the switch port, including FCS.
The allowed range is 1518 bytes to 10000 bytes
Buttons
: Click to apply changes.
Figure 4-3-12: Jumbo Frame Information Page Screenshot
The page includes the following fields:
Object Description
• Jumbo
Displays the current maximum frame size.
