User’s Manual of IGS-4215-16T2S
The page includes the following fields:
Object Description
• Index
Indicates the index of Alarm control entry
• Sample Port
Displays the current sample port
• Sample Variable
Displays the current sample variable
• Sample Interval
Displays the current interval
• Sample Type
Displays the current sample type
• Rising Threshold
Displays the current rising threshold
• Falling Threshold
Displays the current falling threshold
• Rising Event
Displays the current rising event
• Falling Event
Displays the current falling event
• Owner
Displays the current owner
• Action
Click to delete RMON alarm entry
4.2.8.5 RMON History
Configure RMON History table on this page. The RMON History screens in Figure 4-2-45 & Figure 4-2-46 appear.
Figure 4-2-45: RMON History Table Page Screenshot
The page includes the following fields:
Object Description
• Select Index
Select index from this drop-down list to create the new index or modify the index
