User’s Manual of IGS-4215-16T2S
86
 Pkts158to255Octets: The total number of frames (including bad packets)
received and transmitted where the number of octets falls within the
specified range (excluding framing bits but including FCS octets).
 Pkts256to511Octets: The total number of frames (including bad packets)
received and transmitted where the number of octets falls within the
specified range (excluding framing bits but including FCS octets).
 Pkts512to1023Octets: The total number of frames (including bad packets)
received and transmitted where the number of octets falls within the
specified range (excluding framing bits but including FCS octets).
 Pkts1024to1518Octets: The total number of frames (including bad packets)
received and transmitted where the number of octets falls within the
specified range (excluding framing bits but including FCS octets).
• Sample Interval
Sample interval (1–2147483647)
• Sample Type
The method of sampling the selected variable and calculating the value to be
compared against the thresholds, possible sample types are:
 Absolute: Get the sample directly (default).
 Delta: Calculate the difference between samples.
• Rising Threshold
Rising threshold value (0–2147483647)
• Falling Threshold
Falling threshold value (0–2147483647)
• Rising Event
Event to fire when the rising threshold is crossed
• Falling Event
Event to fire when the falling threshold is crossed
• Owner
Specify an owner for the alarm
Buttons
: Click to apply changes.
Figure 4-2-44: RMON Alarm Status Page Screenshot
