User’s Manual of IGS-4215-16T2S
4.5.9 Protocol VLAN Port Setting
This page allows you to map an already configured Group Name to a VLAN/port for the switch. The Protocol VLAN Port
Setting/State screens in Figure 4-5-11 and Figure 4-5-12 appear.
Figure 4-5-11: Protocol VLAN Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Group ID
Protocol Group ID assigned to the Special Protocol VLAN Group.
• Frame Type
Frame Type can have one of the following values:
Ethernet II
IEEE802.3_LLC_Other
RFC_1042
Note: On changing the Frame type field, valid value of the following text field will
vary depending on the new frame type you selected.
• Protocol Value
(0x0600-0xFFFE)
Valid value that can be entered in this text field depends on the option selected
from the preceding Frame Type selection menu.
Valid values for frame type ranges from 0x0600-0xfffe
Buttons
: Click to add protocol VLAN port entry.
Figure 4-5-12: Protocol VLAN Port State Page Screenshot
