User’s Manual of IGS-4215-16T2S
239
The page includes the following fields:
Object Description
• Queue ID
Displays the current queue ID.
• Rate Limit (Kbps)
Displays the current rate limit.
4.12.5 Storm Control
Storm control for the switch is configured on this page.
There is an unknown unicast storm rate control, unknown multicast storm rate control, and a broadcast storm rate control.
These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC Address table.
4.12.5.1 Global Setting
The Storm Control Global Setting and Information screens in Figure 4-12-23 and Figure 4-12-24 appear.
Figure 4-12-23: Storm Control Global Setting Page Screenshot
The page includes the following fields:
Object Description
• Unit
Controls the unit of measure for the storm control rate as "pps" or "bps". The
default value is "bps".
• Preamble & IFG
Set the excluded or included interframe gap.
Buttons
: Click to apply changes.
Figure 4-12-24: Storm Control Global Information Page Screenshot
