The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Static Ports
Displays the current static ports.
• Forbidden Ports
Displays the current forbidden ports.
• Modify
Click to edit parameter.
Click to delete the group ID entry.
4.8.6 IGMP Router Table
This page provides Router Table. The Dynamic, Static and Forbidden Router Table screens in Figure 4-8-15, Figure 4-8-16 and
Figure 4-8-17 appear.
Figure 4-8-15: Dynamic Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port
Displays the current dynamic router ports.
• Expiry Time (Sec)
Displays the current expiry time.
Figure 4-8-16: Static Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port Mask
Displays the current port mask.
