User’s Manual of IGS-4215-16T2S
235
4.12.3.2 Port Settings
The QoS Port Setting and Status screen in Figure 4-12-15 & Figure 4-12-16 appear.
Figure 4-12-15: QoS Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port number from this drop-down list.
• Trust Mode
Enable or disable the trust mode.
Buttons
: Click to apply changes.
Figure 4-12-16: QoS Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Trust Mode
Displays the current trust type.
