User’s Manual of IGS-4215-16T2S
231
4.12.2.5 DSCP Mapping
The DSCP to Queue and Queue to DSCP Mapping screens in Figure 4-12-9 and Figure 4-12-10 appear.
Figure 4-12-9: DSCP to Queue and Queue to DSCP Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list.
• DSCP
Select DSCP value from this drop-down list.
Buttons
: Click to apply changes.
