User’s Manual of IGS-4215-16T2S
194
4.9.2 MLD Static Group
The MLD Static Group configuration screens in Figure 4-9-4 and Figure 4-9-5 appear.
Figure 4-9-4: Add MLD Static Group Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list.
• Group IP Address
The IP address for a specific multicast service.
• Member Ports
Select port number from this drop-down list.
Buttons
: Click to add IGMP router port entry.
Figure 4-9-5: MLD Static Groups Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Group IPv6 Address
Displays the current group IPv6 address.
• Member Ports
Displays the current member ports.
• Modify
Click to edit parameter.
