Users Manual of IGS-4215-16T2S
221
Figure 4-11-2: MAC Address Information Page Screenshot
Object Description
MAC Address
The MAC address of the entry.
VLAN
The VLAN ID of the entry.
Type
Indicates whether the entry is a static or dynamic entry.
Port
The ports that are members of the entry.
Buttons
: Click to add dynamic MAC address to static MAC address.
4.11.2 Dynamic Address Setting
By default, dynamic entries are removed from the MAC table after 300 seconds. The Dynamic Address Setting/Status screens
in Figure 4-11-5 and Figure 4-11-6 appear.
Figure 4-11-3: Dynamic Addresses Setting Page Screenshot
The page includes the following fields:
Object Description
Aging Time
The time after which a learned entry is discarded.
Range: 10-630 seconds;
Default: 300 seconds.
