User’s Manual of IGS-4215-16T2S
185
Figure 4-8-11: IGMP Static Groups Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Group IP Address
Displays the current group IP address.
• Member Ports
Displays the current member ports.
• Modify
Click to edit parameter.
4.8.4 IGMP Group Table
This page provides Multicast Database. The IGMP Group Table screen in Figure 4-8-12 appears.
Figure 4-8-12: IGMP Group Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VID.
• Group IP Address
Displays multicast IP address for a specific multicast service.
• Member Port
Displays the current member port.
• Type
Member types displayed include Static or Dynamic, depending on selected
options.
• Life(Sec)
Displays the current life.
