4.4.6 LAG Status
This page displays LAG status. The LAG Status screens in Figure 4-4-12 and Figure 4-4-13 appear.
Figure 4-4-12: LAG Status Page Screenshot
The page includes the following fields:
Object Description
• LAG
Displays the current trunk entry.
• Name
Displays the current LAG name.
• Type
Displays the current trunk type.
• Link State
Displays the current link state.
• Active Member
Displays the current active member.
• Standby Member
Displays the current standby member.
Figure 4-4-13: LACP Information Page Screenshot
The page includes the following fields:
Object Description
• Trunk
Displays the current trunk ID.
• Port
Displays the current port number.
