Planet IGS-4215 Series User Manual

User’s Manual of IGS-4215-16T2S
199
4.9.7 MLD Snooping Statics
This page provides MLD Snooping Statics. The MLD Snooping Statics screen in Figure 4-9-13 appears.
Figure 4-9-13: MLD Snooping Statistics Page Screenshot
The page includes the following fields:
Object Description
• Total RX
Displays the current total RX.
• Valid RX
Displays the current valid RX.
• Invalid RX
Displays the current invalid RX.
• Other RX
Displays the current other RX.
• Leave RX
Displays the current leave RX.
• Report RX
Displays the current report RX.
• General Query RX
Displays the current general query RX.
• Special Group Query
RX
Displays the current special group query RX.
• Special Group &
Source Query RX
Displays the current special group & source query RX.
• Leave TX
Displays the current leave TX.
• Report TX
Displays the current report TX.
