4.4.4 LACP Setting
This page is used to configure the LACP system priority setting. The LACP Setting screens in Figure 4-4-8 and Figure 4-4-9
appear.
Figure 4-4-8: LACP Setting Page Screenshot
The page includes the following fields:
Object Description
• System Priority
A value which is used to identify the active LACP.
The Industrial Managed Switch with the lowest value has the highest priority and
is selected as the active LACP peer of the trunk group.
Buttons
: Click to apply changes.
Figure 4-4-9: LACP Information Page Screenshot
The page includes the following fields:
Object Description
• System Priority
Displays the current system priority.
