Planet IGS-4215 Series - MLD Router Table

User’s Manual of IGS-4215-16T2S
197
4.9.5 MLD Router Table
This page provides Router Table. The Dynamic, Static and Forbidden Router Table screens in Figure 4-9-9, Figure 4-9-10 and
Figure 4-9-11 appear.
Figure 4-9-9: Dynamic Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port
Displays the current dynamic router ports.
• Expiry Time (Sec)
Displays the current expiry time.
Figure 4-9-10: Static Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Displays the current VLAN ID.
• Port Mask
Displays the current port mask.
Figure 4-9-11: Forbidden Router Table Page Screenshot
