User’s Manual of IGS-4215-16T2S
227
4.12.2.2 QoS Port Settings
The QoS Port Settings and Status screen in Figure 4-12-3 and Figure 4-12-4 appear.
Figure 4-12-3: QoS Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number for this drop down list.
• CoS Value
Select CoS value for this drop down list.
• Remark CoS
Disable or enable remark CoS.
• Remark DSCP
Disable or enable remark DSCP.
• Remark IP Precedence
Disable or enable remark IP Precedence.
Buttons
: Click to apply changes.
 QoS Port Status
Figure 4-12-4: QoS Port Status Page Screenshot
