User’s Manual of IGS-4215-16T2S
2.2.2 DIN-rail Mounting
This section describes how to install the Industrial Managed Switch. There are two methods to install the Industrial Managed
Switch -- DIN-rail mounting and wall-mount plate mounting. Please read the following sections and perform the procedures in
the order being presented.
Follow all the DIN-rail installation steps as shown in the example.
Step 1: Screw the DIN rail bracket on the Industrial Managed Switch.
Step 2: Lightly slide the DIN rail bracket into the track.
