User’s Manual of IGS-4215-16T2S
The page includes the following fields:
Object Description
• Server Address
Displays the current server address
• SNMP Version
Displays the current SNMP version
• Notify Type
Displays the current notify type
• Community Name
Displays the current community name
• UDP Port
Displays the current UDP port
• Time Out
Displays the current time out
• Retries
Displays the current retry times
• Action
: Delete the SNMPv1, 2 host entry.
4.2.7.8 SNMPv3 Notification Recipients
Configure SNMPv3 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure 4-2-33 and
Figure 4-2-34 appear.
Figure 4-2-33: SNMPv3 Notification Recipients Page Screenshot
The page includes the following fields:
Object Description
• Server Address
Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
• Notify Type
Set the notify type in traps or informs.
• User Name
Indicates the user string when send SNMP trap packet.
• UDP Port
Indicates the SNMP trap destination port. SNMP Agent will send SNMP message
via this port, the port range is 1~65535.
• Time Out
Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
• Retries
Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
