User’s Manual of IGS-4215-16T2S
• Index
Indicates the index of the history entry
• Sample Port
Select port from this drop-down list
• Bucket Requested
Indicates the maximum data entries associated this History control entry stored
in RMON. The range is from 1 to 50, default value is 50
• Interval
Indicates the interval in seconds for sampling the history statistics data. The
range is from 1 to 3600, default value is 1800 seconds.
• Owner
Specify an owner for the history
Buttons
: Click to apply changes.
Figure 4-2-46: RMON History Status Page Screenshot
The page includes the following fields:
Object Description
• Index
Displays the current index
• Data Source
Displays the current data source
• Bucket Requested
Displays the current bucket requested
• Interval
Displays the current interval
• Owner
Displays the current owner
• Action
Click to delete RMON history entry.
