User’s Manual of IGS-4215-16T2S
206
• Port Select
Select port from this drop-down list.
• Optional TLV Select
Configures the information included in the TLV field of advertised messages.
 System Name: When checked the "System Name" is included in LLDP
information transmitted.
 Port Description: When checked the "Port Description" is included in
LLDP information transmitted.
 System Description: When checked the "System Description" is
included in LLDP information transmitted.
 System Capability: When checked the "System Capability" is included
in LLDP information transmitted.
 802.3 MAC-PHY: When checked the "802.3 MAC-PHY" is included in
LLDP information transmitted.
 802.3 Link Aggregation: When checked the "802.3 Link Aggregation" is
included in LLDP information transmitted.
 802.3 Maximum Frame Size: When checked the "802.3 Maximum
Frame Size" is included in LLDP information transmitted.
 Management Address: When checked the "Management Address" is
included in LLDP information transmitted.
 802.1 PVID: When checked the "802.1 PVID" is included in LLDP
information transmitted.
Buttons
: Click to apply changes
Figure 4-10-4: LLDP Port Status Page Screenshot
