User’s Manual of IGS-4215-16T2S
Power Requirements
Dual 12~48V DC
24V AC
Power Consumption
DC input:
Max. 3.4 watts/11.6BTU (System on)
Max. 12.5 watts/42.7BTU (Full loading)
AC input:
Max. 6 watts/20.5BTU (System on)
Max. 15 watts/51.2BTU (Full loading)
Dimensions (W x D x H) 66 x 107 x 152 mm
Weight 813g
Layer 2 Functions
Port Mirroring
TX/RX/Both
Many-to-1 monitor
Up to 4 sessions
VLAN
802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Link Aggregation
IEEE 802.3ad LACP and static trunk
Cisco ether-channel (Static Trunk)
Up to 8 trunk groups
Up to 8 ports per trunk group with 16Gbps bandwidth
Spanning Tree Protocol
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
STP BPDU Guard, BPDU Filtering and BPDU Forwarding
IGMP Snooping
IPv4 IGMP snooping v1, v2, v3
IGMP querier
IGMP Snooping port filtering
MLD Snooping IPv6 MLD snooping v1, v2, up to 256 multicast groups
Access Control List
IPv4/IPv6 IP-based ACL/MAC-based ACL
IPv4/IPv6 IP-based ACE/MAC-based ACE
QoS
Ingress/Egress Rate Limit per port bandwidth control
8-level priority for switching
- Port number
- 802.1p priority
- DSCP/IP precedence of IPv4/IPv6 packets
- Typical network application
