User’s Manual of IGS-4215-16T2S
145
• Leave Empty (Rx/Tx)
Displays the current leave empty (TX/RX) packets.
• Join In (Rx/Tx)
Displays the current join in (TX/RX) packets.
• Leave In (Rx/Tx)
Displays the current leave in (TX/RX) packets.
• LeaveAll (Rx/Tx)
Displays the current leaveall (TX/RX) packets.
Figure 4-5-19: GVRP Port Error Statistics Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Invalid Protocol ID
Displays the current invalid protocol ID.
• Invalid Attribute Type
Displays the current invalid attribute type.
• Invalid Attribute Value
Displays the current invalid attribute value.
• Invalid Attribute
Length
Displays the current invalid attribute length.
• Invalid Event
Displays the current invalid event.
Buttons
: Click to clear the GVRP Error Statistics.
: Click to refresh the GVRP Error Statistics.
