User’s Manual of IGS-4215-16T2S
• Configuration Revision
Identifier used to identify the configuration currently being used.
The values allowed are between 0 and 65535.
The default value is 0.
Buttons
: Click to apply changes.
Figure 4-6-5: STP Information Page Screenshot
The page includes the following fields:
Object Description
• STP
Displays the current STP state.
• BPDU Forward
Displays the current BPDU forward mode.
• Cost Method
Displays the current cost method.
• Force Version
Displays the current force version.
• Configuration Name
Displays the current configuration name.
• Configuration Revision
Display the current configuration revision.
