User’s Manual of IGS-4215-16T2S
163
Figure 4-6-7: STP Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port.
• Admin Enable
Displays the current STP port mode status.
• External Cost
Displays the current external cost.
• Edge Port
Displays the current edge port status.
• BPDU Filter
Displays the current BPDU filter configuration.
• BPDU Guard
Displays the current BPDU guard configuration.
• P2P MAC
Displays the current P2P MAC status.
