Planet IGS-4215 Series User Manual

User’s Manual of IGS-4215-16T2S
165
When exceeded, transmission of the next BPDU will be delayed. Valid values are
in the range 1 to 10 BPDU's per second.
• Hello Time
The time that controls the switch to send out the BPDU packet to check STP
current status.
Enter a value between 1 through 10.
Buttons
: Click to apply changes.
Figure 4-6-9: CIST Instance Information Page Screenshot
The page includes the following fields:
Object Description
• Priority
Displays the current CIST priority.
• Max Hop
Displays the current Max.hop.
• Forward Delay
Displays the current forward delay.
• Max Age
Displays the current Max.Age.
• Tx Hold Count
Displays the current Tx hold count.
• Hello Time
Displays the current hello time.
