User’s Manual of IGS-4215-16T2S
169
Figure 4-6-14: MST Instance Status Page Screenshot
The page includes the following fields:
Object Description
• MSTI ID
Displays the MSTI ID.
• Regional Root Bridge
Displays the current designated root bridge.
• Internal Root Cost
Displays the current internal root cost.
• Designated Bridge
Displays the current designated bridge.
• Root Port
Displays the current root port.
• Max Age
Displays the current max. age.
• Forward Delay
Displays the current forward delay.
• Remaining Hops
Displays the current remaining hops.
• Last Topology Change
Display the current last topology change.
