User’s Manual of IGS-4215-16T2S
182
Figure 4-8-6: IGMP Snooping Information Page Screenshot
The page includes the following fields:
Object Description
• IGMP Snooping Status
Displays the current IGMP snooping status.
• IGMP Snooping Version
Displays the current IGMP snooping version.
• IGMP Snooping V2 Report
Suppression
Displays the current IGMP snooping v2 report suppression.
Figure 4-8-7: IGMP Snooping Information Page Screenshot
The page includes the following fields:
Object Description
• Entry No.
Displays the current entry number.
• VLAN ID
Displays the current VLAN ID.
• IGMP Snooping Operation
Status
Displays the current IGMP snooping operation status.
• Router Ports Auto Learn
Displays the current router ports auto learning.
• Query Robustness
Displays the current query robustness.
• Query Interval (sec.)
Displays the current query interval.
• Query Max Response
Interval (sec.)
Displays the current query max response interval.
• Last Member Query count
Displays the current last member query count.
• Last Member Query
Interval (sec)
Displays the current last member query interval.
• Immediate Leave
Displays the current immediate leave.
