User’s Manual of IGS-4215-16T2S
191
Figure 4-8-20: Filter Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number from this drop-down list.
• Filter Profile ID
Select filter profile ID from this drop-down list.
Buttons
: Click to apply changes.
Figure 4-8-21: Port Filter Status Page Screenshot
The page includes the following fields:
Object Description
• Port
Displays the current port.
• Filter Profile ID
Displays the current filter profile ID.
• Action
Click to display detail profile parameter.
Click to delete the IGMP filter profile entry.
