User’s Manual of IGS-4215-16T2S
233
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list.
• IP Precedence
Select IP Precedence value from this drop-down list.
Buttons
: Click to apply changes.
Figure 4-12-12: IP Precedence Mapping Page Screenshot
The page includes the following fields:
Object Description
• IP Precedence
Displays the current CoS value.
• Mapping to Queue
Displays the current mapping to queue.
• Queue
Displays the current queue value.
• Mapping to IP
Precedence
Displays the current mapping to IP Precedence.
