User’s Manual of IGS-4215-16T2S
4.13.6.10 Option82 Circuit-ID Setting
Set creation method for option82, users can define the parameters of circuit-id suboption by themselves. Option82 Circuit-ID
Setting screens in Figure 4-13-47 and Figure 4-13-48 appear.
Figure 4-13-47: Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list.
• VLAN
Indicates the ID of this particular VLAN.
• Circuit ID
Set the option1 (Circuit ID) content of option 82 added by DHCP request packets.
Buttons
: Click to apply changes.
Figure 4-13-48: Option82 Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Displays the current port.
• VLAN
Displays the current VLAN.
• Circuit ID
Displays the current circuit ID.
