User’s Manual of IGS-4215-16T2S
301
4.13.8.2 Binding Table
The IP Source Guard Static Binding Entry and Table Status screens in Figure 4-13-60 and Figure 4-13-61 appear.
Figure 4-13-60: IP Source Guard Static Binding Entry Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list.
• VLAN ID
Indicates the ID of this particular VLAN.
• MAC Address
Sourcing MAC address is allowed.
• IP Address
Sourcing IP address is allowed.
Buttons
: Click to add authentication list
Figure 4-13-61: IP Source Guard Binding Table Status Page Screenshot
The page includes the following fields:
Object Description
• Port
Displays the current port.
• VLAN ID
Displays the current VLAN.
• MAC Address
Displays the current MAC address.
• IP Address
Displays the current IP Address.
• Type
Displays the current entry type.
• Lease Time
Displays the current lease time.
• Action
Click to delete IP source guard binding table status entry.
